Air Filter Expanded Metal Mesh for filtration

Expanded metal filters are particularly useful in industrial and can also be utilized for such unique purposes as electro magnetic interrupt filters in electronic and electrical enclosures.

Inquire Now Next Product

Product parameters

parameters for Air Filter Expanded Metal Mesh for filtration:

XS/XG Expanded Metal	Thickness	Strand	LWDXSWD	LWM	SWM
Expanded Metal XS-31	1.2	1.5	30.5x12	1220	2440
Expanded Metal XS-32	1.6	2	30.5x12	1220	2440
Expanded Metal XS-32	1.6	2	30.5x12	1220	2440
Expanded Metal XS-33	2.3	3	30.5x12	1220	2440
Expanded Metal XS-41	1.6	2	50.8x22	1220	2440
Expanded Metal XS-42	2.3	2.5	50.8x22	1220	2440
Expanded Metal XS-43	3.2	3.5	50.8x22	1220	2440
Expanded Metal XS-51	1.6	2.5	61x25	1220	2440
Expanded Metal XS-52	2.3	3	61x25	1220	2440
Expanded Metal XS-53	3.2	4	61x25	1220	2440
Expanded Metal XS-61	2.3	3	76.2x34	1220	2440
Expanded Metal XS-62	3.2	4	76.2x34	1220	2440
Expanded Metal XS-63	4.5	5	76.2x34	1220	2440
Expanded Metal XS-71	2.3	3.5	152.4x50	1220	2440
Expanded Metal XS-72	3.2	4	152.4x50	1220	2440
Expanded Metal XS-73	4.5	5	152.4x50	1220	2440
Expanded Metal XS-81	3.2	4	203.2x75	1220	2440
Expanded Metal XS-82	4.5	5	203.2x75	1220	2440
Expanded Metal XS-83	6	6	203.2x75	1220	2440
Expanded Metal XS-91	3.2	5	304.8X115	1220	2440
Expanded Metal XS-92	4.5	6	304.8X115	1220	2440
Expanded Metal XS-93	6	7	304.8X115	1220	2440
Expanded Metal XG-11	4.5	7	135.4x34	1220	2440
Expanded Metal XG-12	6	7	135.4x34	1220	2440
Expanded Metal XG-13	6	9	135.4x34	1220	2440
Expanded Metal XG-14	8	9	135.4x34	1220	2440
Expanded Metal XG-21	4.5	7	101.6x36	1220	2440
Expanded Metal XG-22	6	7	101.6x36	1220	2440
Expanded Metal XG-23	6	9	101.6x36	1220	2440
Expanded Metal XG-24	8	9	101.6x36	1220	2440

Flattened Expanded Metal for Air Filter Expanded Metal Mesh for filtration
Flattened Expanded Metal Style	Weight in lbs.per C.S.F	Standard Size in feet	SWD	LWD	Size of Strands in inches


Flattened Expanded 1/4" #20	83	4X8	0.255	1.030	0.086	0.03
Flattened Expanded 1/4" #18	111	4X8	0.255	1.030	0.086	0.04
Flattened Expanded 1/2" #20	40	4X8	0.500	1.260	0.07	0.029
Flattened Expanded 1/2" #18	66	4X8,4X10,5X10	0.500	1.260	0.109	0.039
Flattened Expanded 1/2" #16	82	4X8,4X10,5X10	0.500	1.260	0.103	0.05
Flattened Expanded 1/2" #13	140	4X8,4X10,5X10	0.500	1.260	0.122	0.07
Flattened Expanded 3/4" #16	51	4X8,4X10,5X10	0.923	2.100	0.115	0.048
Flattened Expanded 3/4" #14	63	4X8,4X10,5X10	0.923	2.100	0.119	0.061
Flattened Expanded 3/4" #13	75	4X8,4X10,5X10	0.923	2.100	0.119	0.07
Flattened Expanded 3/4" #10	114	4X8	0.923	2.100	0.16	0.07
Flattened Expanded 3/4" #9	171	4X8,4X10,5X10	0.923	2.100	0.164	0.12
Flattened Expanded 1" #10	165	4X8	1.090	2.560	0.16	0.11
Flattened Expanded 1 1/2" #16	38	4X8	1.330	3.200	0.123	0.048
Flattened Expanded 1 1/2" #14	46	4X8,4X10,5X10	1.330	3.200	0.138	0.06
Flattened Expanded 1 1/2" #13	57	4X8,4X10,5X10	1.330	3.200	0.138	0.07
Flattened Expanded 1 1/2" #12	66	4X8	1.330	3.200	0.116	0.085
Flattened Expanded 1 1/2" #10	165	4X8	1.330	3.200	0.188	0.11
Flattened Expanded 1 1/2 “ #9	111	4X8,4X10,5X10	1.330	3.200	0.175	0.11

When you order air filter Expanded Metal Sheet,pls state:

Japan Standard JIS Expanded Metal

Product Features

Expanded Aluminum Metal air filters are available in aluminum, galvanized steel and stainless steel for use in restaurant, food processing and high heat applications.

Scope of application

Expanded Metal air filters are most commonly used in heating, ventilating and air-conditioning systems, as well as kitchen range hoods, air intake and cabinet filters, roughing filters, prefilters and moisture eliminating filters. An extensive line of washable expanded metal mesh commercial filters are available from us in a number of models to suit just about any application
